• Only five basic ranges cover pressures from 4 kPa to 4 MPa
• Programmable current output 4 to 20 mA with HART communication
• Possibility of easy remote configuration, trim start and end, range setting and reversal
• Accuracy 0.2 or 0.1 %, miniature dimensions
• Stainless steel diaphragm, various input designs including front-flush diaphragm
• Remote reconfiguration by HARTConf configurator or by the HARTWinConf software and standard HART modem



   Links and documentation:

• Manual (En)
